Product Code | MT-MX-50 | MT-MX-100 | MT-MX-200 | MT-MX-300 |
Permeate flow( L/H) | 300-750 | 800-1500 | 1500-2500 | 2500-4500 |
Recovery( %) | 80-95 | 80-95 | 90-95 | 90-95 |
Resistivity( MΩ.cm) | >=15 | >=15 | >=15 | >=15 |
Working voltage( VDC) | 15-100 | 30-150 | 50-150 | 90-200 |
Working current( ADC) | 2- 4 | 2- 4 | 2- 4 | 2- 4 |
Designing voltage( VDC) | <=200 | <=200 | <=200 | <=200 |
Designing current( ADC) | <=5.0 | <=5.0 | <=5.0 | <=5.0 |
Inlet pressure( Mpa) | 0.2- 0.5 | 0.2-0.5 | 0.2-0.5 | 0.2-0.5 |
Max. inlet pressure( Mpa) | 0.6 | 0.6 | 0.6 | 0.6 |
Dilute water/ Permeate | DN25 | DN25 | DN25 | DN25 |
Concentrated water/ outlet | DN15 | DN15 | DN15 | DN15 |
