ISO9001, CE
99.5%
Industry
250L/Hr to 20t/Hr
Electrical Power
SS304
| Quantity: | |
|---|---|
| Product Code | MTC05M01 | MTC10M01 | MTC20M01 | MTC30M01 | MTC30M02 | MTC30M03 | MTC30M04 |
| Number of Models | 1 | 1 | 1 | 1 | 2 | 3 | 4 |
| Min Flow (m³/hr) | 0.3 | 0.8 | 1.5 | 2.5 | 5 | 7.5 | 10 |
| Nom Flow (m³/hr) | 0.5 | 1.13 | 2 | 3.5 | 6.5 | 9.5 | 12.5 |
| Max Flow (m³/hr) | 0.75 | 1.5 | 2.5 | 4.5 | 9 | 13.5 | 18 |
| Typical recovery | 90~95% | 90~95% | 90~95% | 90~95% | 90~95% | 90~95% | 90~95% |
| Inlet | 1" | 1" | 1" | 1" | 1" | 2" | 2" |
| Outlet | 1" | 1" | 1" | 1" | 1" | 2" | 2" |
| Drain | 1/2" | 1/2" | 1/2" | 1/2" | 1/2" | 1" | 1" |
| Inlet Max. Pre.(psi) | 100 | ||||||
| Max Pre. Drop(psi) | 23~35 | ||||||
| Max. Temperature | <45ºC | ||||||
| Voltage | 220/240/380VAC.50/60HZ | 380/480/575VAC,50/60HZ | |||||
| Amperage | 20 | 20 | 30 | 20 | 20 | 30 | 40 |
| L×D×H (cm) | 100×120×181 | 100×120×181 | 100×120×181 | 100×120×181 | 100×165×181 | 100×165x181 | 100×165×181 |
| Ship Weight(kg) | 100 | 120 | 150 | 250 | 400 | 550 | 600 |
