CE, ISO9001, Wqa
FRP
Ionizer
Environmental Protection, Chemical Industry, Water Filter System
Blue/Natural/Gray/Black
Pressure
Availability: | |
---|---|
Quantity: | |
No. | Size | Liner Material | Opening | A Diameter | B Height Without Base | C Height With Base | Capacity | ||||||
(In) | (mm) | Top | Bottom | (In) | (mm) | (In) | (mm) | (In) | (mm) | Gallons | Liters | ||
1 | 06×18 | 140×457 | PE | 2.5" Threaded | N/A | 6 | 152 | 18 | 455 | 18.5 | 470 | 1.1 | 4.2 |
2 | 07×24 | 170×610 | PE | 2.5"Threaded | N/A | 7 | 181 | 24 | 610 | 24.5 | 624 | 3.8 | 15 |
3 | 07×35 | 170×890 | PE | 2.5"Threaded | N/A | 7 | 181 | 35 | 890 | 35.6 | 905 | 5.2 | 19.7 |
4 | 08×17 | 200×430 | PE | 2.5"Threaded | N/A | 8 | 206 | 17 | 430 | 17.6 | 445 | 3.1 | 11.7 |
5 | 08×35 | 200×890 | PE | 2.5"Threaded | N/A | 8 | 206 | 35 | 890 | 35.6 | 905 | 6.6 | 25 |
6 | 08×44 | 200×1115 | PE | 2.5"Threaded | N/A | 8 | 206 | 43.9 | 1115 | 44.5 | 1130 | 8.7 | 32.9 |
7 | 09×35 | 220×890 | PE | 2.5"Threaded | N/A | 9 | 232 | 35 | 890 | 35.6 | 905 | 8.3 | 31.4 |
8 | 09×40 | 220×1005 | PE | 2.5"Threaded | N/A | 9 | 232 | 40 | 1005 | 40.2 | 1020 | 9.5 | 36 |
9 | 09×48 | 220×1005 | PE | 2.5"Threaded | N/A | 9 | 232 | 48 | 1215 | 48.4 | 1225 | 12.7 | 48 |
10 | 10×17 | 240×430 | PE | 2.5"Threaded | N/A | 10 | 257 | 17 | 430 | 17.6 | 445 | 4.8 | 18.2 |
11 | 10×35 | 240×890 | PE | 2.5"Threaded | N/A | 10 | 257 | 35 | 890 | 35.6 | 905 | 10.2 | 38.6 |
12 | 10×44 | 240×1115 | PE | 2.5"Threaded | N/A | 10 | 257 | 43.9 | 1115 | 44.5 | 1130 | 13.1 | 49.6 |
13 | 10×54 | 240×1370 | PE | 2.5"Threaded | N/A | 10 | 257 | 54.1 | 1375 | 54.7 | 1390 | 16.4 | 62 |
14 | 12×52 | 300×1320 | PE | 2.5"Threaded | N/A | 12 | 308 | 52 | 1320 | 52.8 | 1340 | 22.2 | 84 |
15 | 12×52 | 300×1320 | PE | 4.5"Threaded (BTRS) | N/A | 12 | 308 | 52 | 1320 | 52.8 | 1340 | 22.2 | 84 |
16 | 13×54 | 330×1370 | PE | 2.5"Threaded | N/A | 13 | 334 | 54 | 1370 | 54.7 | 1390 | 27.5 | 104 |
17 | 14×65 | 350×1620 | PE | 2.5"Threaded | N/A | 14 | 360 | 63.8 | 1620 | 64.6 | 1640 | 40.6 | 154 |
18 | 14×65 | 350×1620 | PE | 4"Threaded | N/A | 14 | 360 | 63.8 | 1620 | 64.6 | 1640 | 40.6 | 154 |
19 | 16×65 | 400×1620 | PE | 2.5"Threaded | N/A | 16 | 410 | 63.8 | 1620 | 64.6 | 1640 | 49 | 185 |
20 | 16×65 | 400×1620 | PE | 4"Threaded | N/A | 16 | 410 | 63.8 | 1620 | 64.6 | 1640 | 49 | 185 |
21 | 16×65 | 400×1620 | PE | 4"Threaded | 4"Threaded | 16 | 410 | 63.8 | 1620 | 64.6 | 1640 | 49 | 185 |
22 | 18×65 | 450×1650 | PE | 4"Threaded | N/A | 18.5 | 470 | 65.6 | 1665 | 74.9 | 1902 | 66.8 | 253 |
23 | 4"Threaded | 4"Threaded | 18.5 | 470 | 65.6 | 1665 | 74.9 | 1902 | 66.8 | 253 | |||
24 | 20×72 | 500×1800 | PE | 4"Threaded | N/A | 20.5 | 520 | 70.9 | 1800 | 80.4 | 2042 | 89 | 337 |
25 | 4"Threaded | 4"Threaded | 20.5 | 520 | 70.9 | 1800 | 80.4 | 2042 | 89 | 337 | |||
26 | 21×62 | 530×1600 | PE | 4"Threaded | N/A | 21.7 | 550 | 63 | 1600 | 72.5 | 1842 | 88 | 333 |
27 | 4"Threaded | 4"Threaded | 21.7 | 550 | 63 | 1600 | 72.5 | 1842 | 88 | 333 | |||
28 | 24×72 | 600×1800 | PE | 4"Threaded | N/A | 24.4 | 620 | 70.9 | 1800 | 80.4 | 2042 | 126.8 | 480 |
29 | 4"Threaded | 4"Threaded | 24.4 | 620 | 70.9 | 1800 | 80.4 | 2042 | 126.8 | 480 | |||
30 | 30×72 | 750×1800 | PE | 4"Threaded | N/A | 30.5 | 775 | 70.9 | 1800 | 80.5 | 2045 | 195.5 | 740 |
31 | 4"Threaded | 4"Threaded | 30.5 | 775 | 70.9 | 1800 | 80.5 | 2045 | 195.5 | 740 | |||
32 | 36×72 | 900×1800 | PE | 4"Threaded | N/A | 36.4 | 925 | 70.9 | 1800 | 84.4 | 2145 | 283 | 1071 |
33 | 4"Threaded | 4"Threaded | 36.4 | 925 | 70.9 | 1800 | 84.4 | 2145 | 283 | 1071 | |||
34 | 40×72 | 1000×1800 | PE | 6" FLG | 6" FLG | 40.4 | 1025 | 70.9 | 1800 | 84.6 | 2148 | 338.7 | 1282 |
35 | 42x 72 | 1070x1800 | PE | 6" FLG | 6" FLG | 42.4 | 1070 | 70.9 | 1800 | 84.6 | 2148 | 346 | 1310 |
36 | 48×72 | 1200×1800 | PE | 6" FLG | 6" FLG | 48.2 | 1225 | 70.9 | 1800 | 82.9 | 2105 | 477.7 | 1808 |
38 | 60X86 | 1500x2150 | PE | 6" FLG | 6" FLG | 60.2 | 1530 | 84.69 | 2150 | 96.31 | 2453 | 840 | 3179 |
40 | 63X86 | 1575X2150 | PE | 6" FLG | 6" FLG | 61.45 | 1560 | 84.69 | 2150 | 96.31 | 2453 | 924.7 | 3500 |
