Commercial RO System- LCRO Series
Martin LCRO Series Reverse Osmosis Systems cover a wide range production from 800 to 18000GPD with easy installation and low maintenance. System is high quality components designed and 100% factory & industry tested. Years of trouble free service offered.
Standard Feature:
* Stainless Steel 304 frame
* Thin film composite membranes
* Stainless Steel 304 RO vessels seamless
* Vertical high pressure pumps
* PLC control
* 5 micron pre- filter
* Product water flow meter
* concentrate water flow meter
* High pressure pump inlet pressure gauge
* High pressure pump outlet pressure gauge
* Concentrate outlet pressure gauge
* Low pressure switch
* High pressure switch
* Heavy- duty PVC piping
* Level control on/ off
* Automatic flush
* Low pressure shut- off
| Product Code | Capacity (Minimum) | Membrane Quantity | Inlet Pipe | Motor |
| LCRO-800 | 800GPD(125L/hr) | 4021*1 | 3/4" | 0.5 HP/50Hz |
| LCRO-1500 | 1500GPD(250L/hr) | 4040*1 | 3/4" | 1.0 HP/50Hz |
| LCRO-3000 | 3000GDP(500L/hr) | 4040*2 | 3/4" | 1.0 HP/50Hz |
| LCRO-4500 | 4500GDP(750L/hr) | 4040*3 | 1" | 2.0 HP/50Hz |
| LCRO-6000 | 6000GDP(1000L/hr) | 4040*4 | 1" | 2.0 HP/50Hz |
| LCRO-7500 | 7500GDP(1250L/hr) | 4040*5 | 1" | 3.0 HP/50Hz |
| LCRO-9000 | 9000GDP(1500L/hr) | 4040*6 | 1" | 3.0 HP/50Hz |
| LCRO-12000 | 12000GDP(2000L/hr) | 4040*8 | 1-1/2" | 3.0 HP/50Hz |
| LCRO-18000 | 18000GDP(3000L/hr) | 4040*12 | 1-1/2" | 4.0 HP/50Hz |
Detailed Pictures
