Reverse Osmosis
Environmental Protection, Chemical Industry, ISO9001,Wqa
Electric power
CE, RoHS, ISO9001,Wqa
Carton
G-STG
| Quantity: | |
|---|---|
| Flow Rate( 50PSI/ 3.5bar) | |||
| Valve Alone | |||
| Continuous( 15PSI/ 1 bar Drop) | 20GPM/ 76LPM | ||
| Peak( 25PSI/ 1.7 bar Drop) | 26GPM/ 98LPM | ||
| Max Backwash( 25PSI/ 1.7 bar Drop) | 17GPM/ 64LPM | ||
| CV(1PSI/ 0.07bar Drop) | 5.0 | ||
| Softener( 15PSI/ 1 bar Drop) | |||
| 8"44"@0.75cf/ 21L resin | 9.6GPM/36.5LPM | ||
| 9"48"@1.0cf/29L resin | 11.5GPM/43.5LPM | ||
| 10"54"@1.5cf/ 43L resin | 11.8GPM/44.5LPM | ||
| 12"48"@12.8L resin | 12.8GPM/48.5LPM | ||
| 14"64"@3.0cf/84L resin | 14.5GPM/55LPM | ||
| 16"65"@4.0cf/113L resin | 15GPM/57LPM | ||
| Regeneration | |||
| Downflow/Upflow | Both | ||
| Cycles | 5.0 | ||
| Adjustable cycles | All | ||
| Time available | Up to 999 Minutes per cycle | ||
| Flow Meter | |||
| Accuracy range | 0.25-15GPM/0.95-57LPM+5% | ||
| Capacity range | 1-9,999,999 | ||
| Mounting& Shipping | |||
| Inlet/Outlet | 1" or 3/4",NPT or BSP | ||
| Base | 2-1/2" 8 NPSM | ||
| Distriutor pilot | 1.05" OD | ||
| Drain line | 1/2" ID | ||
| Brine line | 3/8" OD or 3/4" OD | ||
| Working | |||
| Electrical rating | 220V/110V/24V-50Hz/60Hz | ||
| Max. VA Water Pressure | 3VA Hydrostatic:300PSI/20bar | ||
| Working:20-120PSI/1.4bar-8bar | |||
| Temperature | 1-43C/34-11F | ||
