ISO9001, CE
Household
0.5gpm - 264gpm
2-40 Degree Centigrade
SS304, (SS316 Optional)
10 Bar(145psi)
Availability: | |
---|---|
Quantity: | |
Model NO. | MT-EPD-05-PH | MT-EPD-1-PH | MT-EPD-2-PH | MT-EPD-6-PH | MT-EPD-8-PH | MT-EPD-12-PH | |
Flow Rate | 0.5GPM (1.9LPM) | 1GPM (3.8LPM) | 2GPM (7.6LPM) | 6GPM (22.7LPM) | 8GPM (30LPM) | 12GPM (45LPM) | |
DIMENSION | Length | 255mm | 255mm | 370mm | 508mm | 965mm | 965mm |
Diameter | 50.8mm | 50.8mm | 63.5mm | 63.5mm | 63.5mm | 63.5mm | |
Controller | 98mm(L)*58mm(W)*32mm(H) | ||||||
Packing details carton | 26pcs | 26pcs | 15pcs | 8pcs | 8pcs | 8pcs | |
Cbm per master carton | 0.087 | 0.087 | 0.118 | 0.092 | 0.138 | 0.138 | |
Inlet/Outlet Port Size | 1/4"female | 1/4"female | 1/2" male | 1/2" male | 3/4" male | 3/4" male | |
Volts | 100-240V(50-60Hz) | ||||||
Power Consumption | 8W | 15w | 21W | 33W | 39W | 72W | |
Lamp Power | 6W | 11W | 16W | 25W | 30W | 55W | |
Lamps/Quartz Sleeves | YES | ||||||
Lamp Rated Life (HRS) | >10000H | ||||||
UV Dosage | (30MJ/CM2) | ||||||
Ambient Temperature | 2-40°C | ||||||
Max. Operating Pressure | 10 Bar(145PSI) | ||||||
Audible Lamp Failure | YES | ||||||
Visual "Power On" | YES | ||||||
Chamber Material | SS304, (SS316 Optional) | ||||||
Lamp Type | PHILIP UV LAMP(2-PIN) |
MODEL NO. | MT-EPD-24-PH | MT-EPD-36-PH | MT-EPD-48-PH | MT-EPD-72-PH | MT-EPD-96-PH | MT-EPD-120-PH | MT-EPD-144-PH |
Water Flow | 5.5M3/H 24GPM | 8M3/H 36GPM | 11M3/H 48GPM | 16M3/H 72GPM | 22M3/H 96GPM | 30M3/H 120GPM | 35M3/H 144GPM |
Lam p Rated Life (HRS) | >8000H | ||||||
UV Dos age | (30MJ/CM2) | ||||||
Electricity | 100 - 240V | ||||||
HZ | 50/60 Hz | ||||||
WATTS | 110W | 165W | 220W | 330W | 440W | 550W | 660W |
Lam p Failoure | LED(AUDIBAL AND VISUAL ALARM SYSTEM AVAILABLE) | ||||||
Ballas t/Quartz Sleeves | YES | ||||||
Am bient Tem perature | 2-40°C | ||||||
TIMER | YES | ||||||
NO. OF UV Lam ps | 2*55W | 3*55W | 4*55W | 6*55W | 8*55W | 10*55W | 12*55W |
Dim ens ion (MM) | 965*∮108*1.2 | 965*∮133*1.2 | 965*∮168*1.5 | 965*∮168*1.5 | 965*∮219*1.5 | 965*∮275*2.3 | 965*∮275*2.3 |
Cham er Material | SS304, (SS316 IS OPTIONAL) | ||||||
Inlet / Outlet (NPT) | 1" | 1.5" | 1.5" | 2" | 3" | 4" | 4" |
Inlet / Outlet (NPT) | FLANGE OPTIONAL | ||||||
MAX Operating Pres s ure | 10 BAR | ||||||
UV Lam p Maker | PHILIPS UV LAMP | ||||||
Shipping Ctn Qty (Pcs ) | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
N.W. (KGS) | 7 | 10 | 10 | 16 | 25 | 45 | 45 |
G.W. (KGS) | 8 | 11 | 11 | 17 | 26 | 46 | 46 |
Carton Size (CBM) | 102.5*22.4*42 | 102.5*24.8*45 | 102.5*24.8*45 | 102.5*29.8*55 | 102.5*36.8*65 | 102.5*43.2*73 | 102.5*43.2*73 |
Product Code | FLOW | CONNECTION | Quartz Sleeve | UV |
RATE | BSP | Length (mm) | LAMP NO. | |
MT-P-50 | 1GPM/227LPH | 1/4" BSP | 320 | T510H |
MT-PC-2 | 2GPM/450LPH | 1/4" BSP | 345 | T514H |
MT-PC-3 | 3GPM/680LPH | 1/2" BSP | 375 | T515H |
MT-PC-6 | 6GPM/1360LPH | 1/2" BSP | 552 | T521H |
MT-PC-8 | 8GPM/1810LPH | 1/2" BSP | 700 | T529H |
MT-PC-12 | 12GPM/2720LPH | 3/4" BSP | 930 | T540H |
MT-EB-15 | 15GPM/3400LPH | 1" BSP | 910 | T565 |
MT-EB-20 | 20GPM/4536LPH | 1 1/2" BSP | 910 | T565 |
MT-EB-24 | 24GPM/5443LPH | 1 1/2"BSP | 910 | T585 |
MT-EB-35 | 35GPM/7938LPH | 2" BSP | 910 | T565 |
MT-EB-45 | 45GPM/10200LPH | 2" BSP | 910 | T585 |
MT-EB-120 | 53GPM/12000LPH | 2" BSP | 910 | T565 |
MT-EB-150 | 66GPM/15000LPH | 2 1/2" BSP | 910 | T585 |
