ISO9001, CE
Industry
0.5gpm - 264gpm
2-40 Degree Centigrade
SS304, (SS316 Optional)
10 Bar(145psi)
| Quantity: | |
|---|---|
| Model NO. | MT-EPD-05-PH | MT-EPD-1-PH | MT-EPD-2-PH | MT-EPD-6-PH | MT-EPD-8-PH | MT-EPD-12-PH | |
| Flow Rate | 0.5GPM (1.9LPM) | 1GPM (3.8LPM) | 2GPM (7.6LPM) | 6GPM (22.7LPM) | 8GPM (30LPM) | 12GPM (45LPM) | |
| DIMENSION | Length | 255mm | 255mm | 370mm | 508mm | 965mm | 965mm |
| Diameter | 50.8mm | 50.8mm | 63.5mm | 63.5mm | 63.5mm | 63.5mm | |
| Controller | 98mm(L)*58mm(W)*32mm(H) | ||||||
| Packing details carton | 26pcs | 26pcs | 15pcs | 8pcs | 8pcs | 8pcs | |
| Cbm per master carton | 0.087 | 0.087 | 0.118 | 0.092 | 0.138 | 0.138 | |
| Inlet/Outlet Port Size | 1/4"female | 1/4"female | 1/2" male | 1/2" male | 3/4" male | 3/4" male | |
| Volts | 100-240V(50-60Hz) | ||||||
| Power Consumption | 8W | 15w | 21W | 33W | 39W | 72W | |
| Lamp Power | 6W | 11W | 16W | 25W | 30W | 55W | |
| Lamps/Quartz Sleeves | YES | ||||||
| Lamp Rated Life (HRS) | >10000H | ||||||
| UV Dosage | (30MJ/CM2) | ||||||
| Ambient Temperature | 2-40°C | ||||||
| Max. Operating Pressure | 10 Bar(145PSI) | ||||||
| Audible Lamp Failure | YES | ||||||
| Visual "Power On" | YES | ||||||
| Chamber Material | SS304, (SS316 Optional) | ||||||
| Lamp Type | PHILIP UV LAMP(2-PIN) | ||||||
