Wooden Case
Ss304 Mat Finishing
Martinn
China
Availability: | |
---|---|
Quantity: | |
Product Code | Dimension (mm) | Max Pre. | Max | Bag Filters | Connection | Max Flow | |||
A | B | C | Bar | Temp. | Code | Nos | Inlet/Outlet | M3/H | |
BFH2-3-BT | 180 | 706 | 1500 | 10 | 60 'C | 2 | 3 | 4" | 120 |
BFH2-4-BT | 200 | 756 | 1550 | 10 | 60 -C | 2 | 4 | 5" | 160 |
BFH2-5-BT | 200 | 806 | 1550 | 10 | 60 'C | 2 | 5 | 6" | 200 |
BFH2-6-BT | 220 | 906 | 1620 | 10 | 60 'C | 2 | 6 | 6" | 240 |
BFH2-8-BT | 220 | 1106 | 1700 | 10 | 60 'C | 2 | 8 | 6" | 320 |
BFH2-10-BT | 250 | 1110 | 1860 | 10 | 60 'C | 2 | 10 | 8" | 400 |
BFH2-12-BT | 280 | 1210 | 1860 | 10 | 60 'C | 2 | 12 | 10" | 480 |
BFH2-14-BT | 280 | 1410 | 1900 | 10 | 60 'C | 2 | 14 | 10" | 560 |
BFH2-16-BT | 300 | 1510 | 1900 | 10 | 60 'C | 2 | 16 | 12" | 640 |
BFH2-18-BT | 300 | 1610 | 2250 | 10 | 60 -C | 2 | 18 | 12" | 720 |
BFH2-20-BT | 300 | 1610 | 2250 | 10 | 60 °C | 2 | 20 | 12" | 800 |
