Side-in Side-out
Wooden Case
Ss304 Mat Finishing
Martinn
China
| Quantity: | |
|---|---|
| Product Code | Dimension (mm) | Connection | Cartridges | Flow | ||||
| A | B | C | D | Inlet/Outlet | Nos | Inch | M3/H | |
| SFT5-20-FLG-SD | 450 | 220 | 1000 | 200 | 11/2" | 5 | 20" | 4 |
| SFT5-30-FLG-SD | 500 | 250 | 1200 | 200 | 2" | 5 | 30" | 6 |
| SFT7-20-FLG-SD | 450 | 220 | 1000 | 230 | 11/2" | 7 | 20" | 5.6 |
| SFT7-30-FLG-SD | 500 | 250 | 1200 | 230 | 2" | 7 | 30" | 7.4 |
| SFT12-20-FLG-SD | 600 | 250 | 1050 | 300 | 2" | 12 | 20" | 9.6 |
| SFT12-30-FLG-SD | 600 | 300 | 1300 | 300 | 2" | 12 | 30" | 14.4 |
| SFT12-40-FLG-SD | 600 | 300 | 1600 | 300 | 21/2" | 12 | 40" | 18 |
| SFT15-30-FLG-SD | 600 | 300 | 1400 | 350 | 21/2" | 15 | 30" | 18 |
| SFT15-40-FLG-SD | 600 | 300 | 1600 | 350 | 3" | 15 | 40" | 22.5 |
| SFT20-30-FLG-SD | 800 | 350 | 1450 | 400 | 3" | 20 | 30" | 24 |
| SFT20-40-FLG-SD | 800 | 350 | 1650 | 400 | 3" | 20 | 40" | 30 |
| SFT25-40-FLG-SD | 800 | 400 | 1750 | 450 | 3" | 25 | 40" | 32 |
| SFT30-40-FLG-SD | 800 | 400 | 1800 | 500 | . 4" | 30 | 40" | 40 |
| SFT40-40-FLG-SD | 1000 | 400 | 1950 | 550 | 4" | 40 | 40" | 52 |
| SFT45-40-FLG-SD | 1000 | 500 | 2160 | 600 | 5" | 45 | 40" | 59 |
| SFT50-40-FLG-SD | 1000 | 500 | 2200 | 700 | 5" | 50 | 40" | 65 |
| SFT60-40-FLG-SD | 1000 | 500 | 2200 | 700 | 6" | 60 | 40" | 78 |
| SFT70-40-FLG-SD | 1200 | 600 | 2200 | 800 | 6" | 70 | 40" | 90 |
| SFT80-40-FLG-SD | 1200 | 600 | 2200 | 800 | 6" | 80 | 40" | 105 |
| SFT90-40-FLG-SD | 1200 | 650 | 2400 | 900 | 8" | 90 | 40" | 120 |
| SFT100-40-FLG-SD | 1200 | 700 | 2650 | 1000 | 8" | 100 | 40" | 135 |
| SFT120-40-FLG-SD | 1200 | 700 | 2650 | 1000 | 8" | 120 | 40" | 160 |
