Wooden Case
Ss304 Mat Finishing
Martinn
China
Availability: | |
---|---|
Quantity: | |
Product Code | Dimension (mm) | Connection | Cartridges | Flow | ||||
A | B | C | D | Inlet/Outlet | Nos | Inch | M3/H | |
SFT5-20-FLG-BT | 600 | 200 | 1100 | 200 | 11/2" | 5 | 20" | 4 |
SFT5-30-FLG-BT | 600 | 250 | 1350 | 200 | 2" | 5 | 30" | 6 |
SFT7-20-FLG-BT | 600 | 200 | 1100 | 230 | 11/2" | 7 | 20" | 5.6 |
SFT7-30-FLG-BT | 600 | 250 | 1350 | 230 | 2" | 7 | 30" | 7.4 |
SFT12-20-FLG-BT | 600 | 250 | 1200 | 300 | 2" | 12 | 20" | 9.6 |
SFT12-30-FLG-BT | 600 | 250 | 1400 | 300 | 2" | 12 | 30" | 14.4 |
SFT12-40-FLG-BT | 800 | 300 | 1650 | 300 | 21/2" | 12 | 40" | 18 |
SFT15-30-FLG-BT | 800 | 300 | 1500 | 350 | 21/2" | 15 | 30" | 18 |
SFT15-40-FLG-BT | 800 | 300 | 1700 | 350 | 3" | 15 | 40" | 22.5 |
SFT20-30-FLG-BT | 800 | 300 | 1550 | 400 | 3" | 20 | 30" | 24 |
SFT20-40-FLG-BT | 800 | 300 | 1750 | 400 | 3" | 20 | 40" | 30 |
SFT25-40-FLG-BT | 900 | 300 | 1850 | 450 | 3" | 25 | 40" | 32 |
SFT30-40-FLG-BT | 900 | 350 | 1900 | 500 | 4" | 30 | 40" | 40 |
SFT40-40-FLG-BT | 1000 | 350 | 2050 | 550 | 4" | 40 | 40" | 52 |
SFT45-40-FLG-BT | 1000 | 400 | 2200 | 600 | 5" | 45 | 40" | 59 |
SFT50-40-FLG-BT | 1200 | 500 | 2200 | 700 | 5" | 50 | 40" | 65 |
SFT60-40-FLG-BT | 1200 | 450 | 2200 | 700 | 6" | 60 | 40" | 78 |
SFT70-40-FLG-BT | 1400 | 450 | 2300 | 800 | 6" | 70 | 40" | 90 |
SFT80-40-FLG-BT | 1400 | 450 | 2300 | 800 | 6" | 80 | 40" | 105 |
SFT90-40-FLG-BT | 1400 | 550 | 2500 | 900 | 8" | 90 | 40" | 120 |
SFT100-40-FLG-BT | 1400 | 550 | 2750 | 1000 | 8" | 100 | 40" | 135 |
SFT120-40-FLG-BT | 1400 | 550 | 2750 | 1000 | 8" | 120 | 40" | 160 |
