4040/8040 Stainless Steel RO Membrane Housing

4040/8040 Stainless Steel RO Membrane Housing

Material:
Ss 304/Ss 316
Name:
4040/8040 Stainless Steel RO Membrane Housing
Transport Package:
Carton
Specification:
CE, RoHS, SGS and so on
Trademark:
Martin
Origin:
Shanghai, China

Quantity:
Availability:





Inquire Add to Basket

4040/8040 Stainless Steel RO Membrane Housing Membrane Housing Ro Membrane Housing

Product Description

4040/8040 Stainless Steel RO Membrane Housing

Why Stainless Steel

1. No seals involved in port connections, Unlike fiberglass, doesn't warp or weep
2. Is not affected by UV rays or sunlight
3. Stainless steel is a preferred, Universally accepted and material for water systems
4. Can withstand high temperatures, up to 200° F, Capable of supporting process piping
5. During assembly, stainless housings are lighter and easier to handle than PVC and FRP housings with equivalent pressure ratings

1. End Entry 2.5 and 4 inch Stainless Steel Membrane Housing

Features

1. Stainless Steel 304/316L connections
2. Maximum Operating Pressure 250 PSI (17bar)
3. Stainless Steel, High Polished Exterior
4. End Entry, Smooth & Sleek Look
5. Unique Design saves both Time and Money
6. Competitive Prices, Designed for direct connection to most style of RO elements7. Double O-ring

Materials of Construction

1. End Cap........................................Nylon with Fiber Glass / SS304 End Cap
2. Clamp ................................. 304 SS/316LSS
3.O-ring ...........................................Buna-N
4.Housing Body.............................. 304 SS/316SS
5. Permeate Plug .............................ABS Or Nylon
6. Cap Screws ............................ 304 SS/ 316SS

Note

1) Membrane housings with seam are available, e.g. SS-4040-12WS
2) SS316L membrane housing seamless are available, e.g. SS-4040-12SL-316L
3) Membrane housing seamless side port are available, e.g. SS-4040SP-12SL

End Port 4" 304 Stainless Steel Housing (Seamless)

Product Code	For Membrane	Vessel		Connection Size			Remark1
Product Code	For Membrane	Diameter	Length	Feed	Brine	Product	Remark1
SS-4014-12SL	4014X1PC	4"	16"	1/2"	1/2"	1/2"	Nylon End Cap
SS-4021-12SL	4021X1PC	4"	23"	1/2"	1/2"	1/2"	Nylon End Cap
SS-4040-12SL	4040X1PC	4"	42"	1'/2"	1/2"	1/2"	Nylon End Cap
SS-4040-34SL	4040X1PC	4"	42"	1'/2"	3/4"	1/2"	Nylon End Cap
SS-4080-12SL	4040X2PC	4"	82"	1'/2"	1/2"	1/2"	Nylon End Cap
SS-4080-34SL	4040X2PC	4"	82"	1'/2"	3/4"	1/2"	Nylon End Cap
SS-40120-12SL	4040X3PC	4"	122"	1'/2"	1/2"	1/2"	Nylon End Cap
SS-40120-34SL	4040X3PC	4"	122"	1'/2"	3/4"	1/2"	Nylon End Cap
SS-4014-12SL-304EC	4014X1PC	4"	16"	1/2"	1/2"	1/2"	SS304 End Cap
SS-4021-12SL-304EC	4021X1PC	4"	23"	1/2"	1/2"	1/2"	SS304 End Cap
SS-4040-12SL-304EC	4040X1PC	4"	42"	1'/2"	1/2"	1/2"	SS304 End Cap
SS-4080-12SL-304EC	4040X2PC	4"	82"	1'/2"	1/2"	1/2"	SS304 End Cap
SS-4014-12SL-304DEC	4014X1PC	4"	16"	1/2"	1/2"	1/2"	SS304 Deluxe End Cap
SS-4021-12SL-304DEC	4021X1PC	4"	23"	1/2"	1/2"	1/2"	SS304 Deluxe End Cap
SS-4040-12SL-304DEC	4040X1PC	4"	42"	1'/2"	1/2"	1/2"	SS304 Deluxe End Cap
SS-4080-12SL-304DEC	4040X2PC	4"	82"	1'/2"	1/2"	1/2"	SS304 Deluxe End Cap

2. Side Entry 4 and 8 inch Stainless Steel Membrane Housing

Materials of Construction

End Cap........................................304 SS
Retaining Ring .............................304 SS
Support Straps ............................ 304 SS
Mounting Pads ............................ Rubber
O-ring ...........................................Buna-N
Housing Body.............................. 304 SS seamless
Permeate Plug .............................ABS Or Nylon
Cap Screws .................................304 SS

Options Available

Side Ports .........................1.5-inch port (standard)
..........................................2 and 3-inch port (optional)
..........................................Tri-clamp or Threaded (standard is Victaulic)
Finishes ............................Original steel mill finish (standard)
..........................................Electro-polished for a glossy, shiny, metallic look
Design Options .................High pressure made with 304 stainless steel end caps (300 & 400 psi)
..........................................Sanitary made with polished

4040/8040 Stainless Steel RO Membrane Housing
