STRING WOUND FILTER CARTRIDGE
Martin string wound filter cartridges are structured loose outer layers and tight inner layers which can offer true depth filtration for high dirt holding capacity and extremely low media migration to ensure temperature and chemical compatibility. The main advantage of the string wound filter cartridge is its exceptionally high structural strength, therefore, they can withstand severe operating conditions.
FEATURES:
Fits all the standard housings
Low pressure drop, high dirt holding capacity and long service life
Loose outer layers and tight inner layers offers effective depth filtration
Various filter media fit with various applications
APPLICATIONS:
Food & Beverage
Semiconductor
Pharmaceuticals
SPECIFICATIONS:
Filter media: Polypropylene, cotton, glass fiber
Outside diameter: 55mm, 61mm, 63mm, 65mm, 115mm
Inner diameter: 28mm, 30mm
Length: 5", 10", 20", 30", 40"
Micron Rating (nominal): 1, 5, 10, 20, 30, 50, 75, 100micron
Polypropylene material for non-organic solvent,
Maximum recommended operating temperature <=60° C
Bleached cotton material filter cartridge with stainless core apply to organic solvent, water, oil, alkalinity
Solvent, beverage, pharmaceuticals, and maximum recommended operating temperature: 120° C
Detailed Pictures
